Check details
1、Intelligent control gearbox for more efficient power transmission.
2、600 V high-voltage platform,which has small electric current and less power loss, achieves high efficiency energy transfer.
3、Single gun fast charging interface offers a maximum charging power up to 120 Kw.
4、The battery has a long service life and the battery SOC can increase to 90% from 10% with in 90 minutes.
5、Cab central control is more comfortable and convenient for driving.
| Model | CPD120-180 | |
| Rated capacity | lb | 26400-39600 |
| Load center | in | 23.6 |
| Overall height(overhead guard) | in | 132.5 |
| Overall length(with fork) | in | 264.0 |
| Overall width | in | 100.8 |
| Mast tilting angle (F/R) | ° | 6/12 |
| Mast height (retract/extended) | in | 132.5/191.5 |
| Min. outside turning radius | in | 177.2 |
| Travelling speed(loaded/unloaded) | km/h | 17/19 |
| Lifting speed (loaded/unloaded) | in/s | 12.6/13.4 |
| Max. Gradeability (loaded/unloaded) | % | 25 |
| Battery voltage/rated capacity | V/Ah | 531.3V/302Ah |
| Controller | SANTROLL |
